Shelly Pro Dimmer 2PM Variateur 2 canaux

Description

Shelly Pro Dimmer 2PM Variateur 2 canaux — produit officiel Shelly (réf. 376-stdomo). Disponible chez Tech au Choix avec garantie constructeur et livraison rapide au Maroc.

Présentation

3Professional 2-channel DIN rail smart dimmer with power monitoring

Caractéristiques principales

LAN, Wi-Fi, and Bluetooth connection

Power metering

Free storage data (using Shelly App)

Night mode for lower brightness during night hours

Automatic dimming calibration

Switch/button input mode

Use with your existing switches (one/dual button control)

Adjustable min/max brightness

Adjustable button fade rate and transition time

Non hub required! Easy control through the Shelly Smart Control app, most platforms and protocols, as well as voice assistants. Use it with Alexa, Accueil Assistant, or your preferred automation platform

Wi-Fi Range Extender & BLE Gateway

Extremely fast processor for immediate reaction – ESP32

Supports scripting, webhooks, MQTT, WebSocket, HTTPS, UDP, TLS and custom certificates

Supports KNXnet / IP communication

Caractéristiques

Quantité

Value

Physical

Size (HxWxD):

94x19x69 mm / 3.70×0.75×2.71 in

Weight:

75 g / 2.7 oz

Screw terminals max torque:

0.4 Nm / 3.54 lbin

Conductor cross section:

0.5 to 2.5 mm² / 20 to 14 AWG (green connectors)

0.5 to 1.5 mm² / 20 to 16 AWG (blue connector)

(solid, stranded, and bootlace ferrules)

Conductor stripped length:

6 to 7 mm / 0.24 to 0.28 in (green connectors)

5 to 6 mm / 0.20 to 0.24 in (blue connector)

Mounting:

DIN rail

Shell material:

Plastic

Shell color:

Lime

Environmental

Ambient working temperature:

-20 °C to 40 °C / -5 °F to 105 °F

Humidity:

30 % to 70 % RH

Max. altitude:

2000 m / 6562 ft

Electrical

Power supply:

110 – 240 V~ 50/60 Hz

Power consumption:

< 2 W

External protection:

10 A, tripping characteristic B or C,

6 kA interrupting rating,

Energy limiting class 3

Dimming type:

Trailing edge

Output circuits ratings

Max. output power:

200 W per channel

Sensors, meters

Voltmeter (AC):

Oui

Ammeter (AC):

Oui

Power and energy meters:

Oui

Internal-temperature sensor:

Oui

Radio

Wi-Fi

Protocol:

802.11 b/g/n

RF band:

2401 – 2483 ?Hz

Max. RF power:

< 20 dBm

Range:

Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors

(Depends on local conditions)

Bluetooth

Protocol:

4.2

RF band:

2400 – 2483.5 MHz

Max. RF power:

< 4 dBm

Range:

Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors

(Depends on local conditions)

Microcontroller unit

CPU:

ESP32-D0WDQ6

Flash:

8 MB

Firmware capabilities

Schedules:

20

Webhooks (URL actions):

20 with 5 URLs per hook

Scripting:

Oui

MQTT:

Oui

Points forts

• LAN, Wi-Fi, and Bluetooth connection
• Power metering
• Free storage data (using Shelly App)
• Night mode for lower brightness during night hours
• Automatic dimming calibration
• Switch/button input mode
• Use with your existing switches (one/dual button control)
• Adjustable min/max brightness
• Adjustable button fade rate and transition time
• Non hub required! Easy control through the Shelly Smart Control app, most platforms and protocols, as well as voice assistants. Use it with Alexa, Accueil Assistant, or your preferred automation platform
• Wi-Fi Range Extender & BLE Gateway
• Extremely fast processor for immediate reaction – ESP32
• Supports scripting, webhooks, MQTT, WebSocket, HTTPS, UDP, TLS and custom certificates
• Supports KNXnet / IP communication
